LDO

Monolith CNC Gantry by LDO Systems (V2.4 and Trident compatible with 2WD and AWD)

Monolith CNC Gantry by LDO Systems (V2.4 and Trident compatible with 2WD and AWD)

Prix habituel €235,00 EUR
Prix habituel Prix promotionnel €235,00 EUR
Promotion Épuisé
Taxes incluses. Frais d'expédition calculés à l'étape de paiement.
printer
Quantité

Features:

  • Metal Monolith in an easy-to-assemble, aesthetically pleasing package
  • 2WD and AWD options in one kit to provide a convenient upgrade path
  • Everything included except belts and steppers
  • Robust, removable tensioners for easier belting up and pre-tensioning
  • 9/10mm belt support (toolhead dependent)
  • Genuine Gates pulleys and press-fit live shaft idlers
  • AWD front extrusion support for toolchangers

Recommendations:


  • Made for standard 250-350mm bed sizes
  • Frame upgrades for full performance potential (4040, structural panels)
  • Best paired with non-modular, performance-oriented toolheads, preferably metal
  • LDO 2504 (S45R) Speedy Power steppers (45mm round shaft, 2m long cable)
  • Quality, high-preload X-rail





We recommande using this with LDO-42STH48-2504AH (S45R)

github here!
